1956 TM 11-1247B Test Set TS-147D/UP US Army Technical Manual Radar Communications

Original U.S. Department of the Army Technical Manual TM 11-1247B covering the Test Set TS-147D/UP, issued in May 1956. This manual provides detailed instructions for the installation, operation, theory, maintenance, and testing of the TS-147D/UP, a precision microwave/radar test instrument used to service military communications and radar equipment.

Details:

• Manual Number: TM 11-1247B
• Cross Reference: TO 33A1-3-56-21
• Title: Test Set TS-147D/UP
• Publication Date: May 1956
• Issued by: Department of the Army
• Covers theory of operation, installation, operation, calibration, maintenance, troubleshooting, and repair procedures.
• Includes foldout diagrams and technical illustrations (if present).
